MODEL PS18SPH
19861-300 Rev A (07-20)
© Copyright 2013, Creative Playthings
Page 7
COMPONENT VIEW
Y 9 33953-102 Deck Board 5/4 x 6 x 41-1/2"
Z 3 33954-102 Narr. Deck Board 5/4 x 4 x 38-5/8"
AA 2 33956-102 End Joist 5/4 x 6 x 22"
AB 1 33972-102 Ladder Slat 1 x 4 x 15-3/4"
AC 4 35443-102 Roof Upright 2 x 4 x 20-3/4"
AD 12 33745-402 Roof Board 1 x 6 x 39-1/2"
AE 5 14202-400 1" Dia. x 15" Rung, Green
AF 1 32225-102 Table Cleat 5/4 x 6 x 14"
AG 12 33741-102 Short Wall Slat 1 x 4 x 19-1/2"
AH* 2 33757-102 Swing Mount 2 x 3 x 23-1/2"
AI 5 33920-102 Rock Board 5/4 x 6 x 27"
AJ 1 35440-102 Rock & Rope Board 5/4 x 6 x 27"
AK 6 33962-102 Narrow Wall Slat 1 x 4 x 24-1/2"
AL 2 33963-102 Entrance Slat 5/4 x 6 x 24-1/2"
AM 5 33964-102 Spacer Board 5/4 x 6 x 27"
AN 4 35444-102 Picnic Support 2 x 4 x 59-3/8"
AO 2 35445-102 Seat Cleat 5/4 x 6 x 6"
AP 3 35446-102 Table Board 5/4 x 6 x 44-1/4"
AQ 4 35447-102 Seat Board 2 x 4 x 44-1/4"
AR 2 35448-102 Climber Upright 2 x 3 x 67-1/8"
AS* 5 36515-102 Ground Stake
AT 1 50428-400 Climbing Rocks (6)
AU 3 15034-100 Hand Grips
AV 1 18008-138 Climbing Rope
1 50469-100 Small Name Plate Pack
A 4 32561-102 Angle Brace 2 x 3 x 17-1/4"
B 2 35663-102 Mid Post 2 x 4 x 32-1/2"
C 1 33760-102 Platform Right 2 x 4 x 59-3/8"
D* 1 33761-102 Platform Left 2 x 4 x 59-3/8"
E 2 33949-102 Sandbox End 5/4 x 6 x 41-1/4"
F 2 33950-102 Sandbox Side 5/4 x 6 x 59-1/2"
G 1 33951-102 Platform Front 5/4 x 6 x 41-1/2"
H* 1 33952-102 Platform Back 5/4 x 6 x 41-1/2"
I 1 33955-102 End Support 5/4 x 6 x 41-1/2"
J 1 33968-102 Front Arch 5/4 x 6 x 41-1/2"
K 1 35441-102 Left Wall Supp 5/4 x 6 x 59-1/2"
L 1 35442-102 Right Wall Support 5/4 x 6 x 59-1/2"
M 1 40649-102 Post, Back Left
N 1 40650-102 Post, Back Right
O 1 40651-102 Post, Front Left
P 1 40652-102 Post, Front Right
1 50568-701 Pt Hardware Bag
1 50568-702 Pt Screw Bag
1 50529-300 Instruction Pack, Spring Hill
Q* 1 33732-102 Stringer 2 x 3 x 59-1/2"
R 1 35664-102 Lower Wall Supp. 5/4 x 4 x 59-1/2"
S 1 35665-102 Short Wall Supp. 5/4 x 4 x 23-1/4"
T* 1 33742-102 Ceiling Joist 1 x 4 x 14-5/8"
U 6 33744-102 Rafter 2 x 3 x 31"
V 1 33755-102 Ladder Rail Left 2 x 3 x 63-1/2"
W 1 33756-102 Ladder Rail Right 2 x 3 x 63-1/2"
X 1 33922-102 Rock Wall Mount 5/4 x 6 x 39-1/2"
Take inventory of all parts, making sure nothing is missing or defec-
tive. If you nd that parts are missing or defective call the Creative
Playthings Customer Service Department at 1-800-598-4997.
BOX 2 (CONT'D)
60082-452 BOX 2
60082-453 BOX 3
* Not marked on Play Set View page.
60082-451 BOX 1
