Creative I-TRIGUE L3450 - Connectivity Diagram

Connectivity
Diagram
Right
Satellite
Speaker
Left
Satellite
Speaker
To Analog
Audio
Source
M-PORT
Volume Control
with Power
On/Off Switch
Bass
Level
Control
To Wall Outlet
(Disconnect when not
in use for several
days)
Power Supply Adapter
(Types of adapter may vary
in different countries)
3.5mm (
1
/
8
”)
Stereo Mini-Plug
Subwoofer
Audio
Control
Pod
Note Orientation
