Creative SOUND BLASTER X5 - Powering Up and Connecting Devices; Powering Up the Sound Blaster X5; Connecting Devices to the Front Panel

Button
Button
Action
Action
LED Display
LED Display
x1
x1
x1
Power On
Power On (Standalone Mode)
Power O / Standby
i) Supported USB-A Port
ii) DC Adapter (Min. 5V 1A)
USB-C to USB-A Cable
“WELCOME” is the default LED display when Sound Blaster X5 is connected to a PC / Mac using a USB-C
data cable.
“OFFLINE” is the default LED display when Sound Blaster X5 is powered by an external power source
using a USB-C charging cable and has devices connected to one or more of the available input sources.
Use cases include, but not limited to: TV, Blu-ray / DVD player, and / or a set-top box
POWERING UP SOUND BLASTER X5 CONNECTING EXTERNAL DEVICES TO SOUND BLASTER X5 (FRONT)
Balanced Headphones
Microphone
USB
Headphones / Headset / Earphones
54
