OVERVIEW (FRONT) OVERVIEW (BACK)
1. Power Button with LED
2. Mic Mute / Unmute Button with LED
3. Bluetooth
®
Button with LED
4. Mic Gain Knob
5. Info Display Button
6. Headphones Gain Switch
7. LED Display
8. Speaker / Headphones Switch Button
16. Line-out (Right) Port
17. Line-out (Left) Port
18. Line-in (Right) Port
19. Line-in (Left) Port
9. Mic-in Port
10. DSP / Direct Mode Switch Button
11. Headphones-out (Unbalanced) Port
12. Equalizer Button
13. Headphones-out (Balanced) Port
14. PC / Console Switch
15. Volume Control Knob with LED
20. TOSLINK Optical-out Port
21. TOSLINK Optical-in Port
22. USB-C Power and Data Transfer Port
23. USB-A Host Audio Streaming Port
(Max. Power 5V 100 mA)
8 9 16 2018 2217 2119 2311 1310 12 14
1 2 4 63 5 7
32
15
