Creative ZiiSound D5x - Page 5

6
5
2
1
3
4
4
1.1
Product Overview / Connectivity Diagram
Section 1 : D5x Basic operations
*Fora1.1setup,theZiiSoundD5xwilllightuptheCenterSpeakerLEDtoindicateitisconnectedina1.1setup.
Pairing
Rapid blinking LED
Bluetooth Connected
Steady Lit
For various Bluetooth Pairing activities
Forvariousspeakerslinkingactivities
(Slave) Left Speaker (Slave/Master*) Center Speaker (Master) Right Speaker
1
2
3
4
6
5
TransmitterBaywithEZ-Charge
TM
CONNECTLEDStatusIndicator
CONNECTTouchpad/Button
LINKTouchPad/Button
LINKLEDStatusIndicator
VolumeTouchpad/ButtonandVolumeLedStatusIndicator
Link discoverable mode
Rapid blinking LED
