Creative ZiiSound D5x - Page 6

B
C
A
11
10
9
7
8
5
1.2
Overview of Wireless Transmitter
A
B
C
Wireless Bluetooth Transmitter (BT-D5)
TobeusedwithiPhone/iPod.SeeTable1foralistof
compatible iPhone and iPod models.
Transmitter LED Status Indicator
BlueLEDblinksatdifferentintervalstoindicate
wirelesslinkstatus
Pairing Button
PressandholdthistoinitiatevariousWireless
Transmitterpairingactivities
7
DockforSupportStand
8
BassPortTube
9
AUX-IN
10
Power ON / Standby Button
11
DC–IN*
*AllLEDswilllightupforafewsecondswhenthemainsareappliedtotheD5x.Thisisnormal.
