Tall Cabinet Ventilation
35
Ventilation Slot required
here if cabinet does not
fit to ceiling -51mm x 457mm min. area
50mm
Air Gap
50mm
Air Gap
Ventilation Slot
required
here if the cabinet
does fit to the ceiling -
51mm x 457mm min.
area
Ventilation Slot
required here
51mm x 457mm
min. area
Fig. 1
