31
577mm
exc. handle
knobs
565
887mm
597mm
560mm
560-574mm
875mm
887mm
878mm if
cooker
trim
is to
overlap
top edge
of shelf
* excluding pipe work
and other projections
Oven Door
Fig. 3
Fig. 4
Fig. 2
550mm
565mm
min *
The appliance can be installed into a
cabinet of minimum depth 550mm pro-
viding a suitable means of
connection to the gas supply can be
made.
560mm
Viewed down
through cabinet
No. 6 x 15mm screw
(4 supplied)
Cabinet
