TALL CABINET VENTILATION
30
Ventilation Slot required
here if cabinet does not
fit to ceiling -50mm x 450mm min. area
30mm
Air Gap
30mm
Air Gap
Ventilation Slot
required
here if the cabinet
does fit to the ceiling -
50mm x 450mm min.
area
Ventilation Slot
required here
50mm x 450mm
min. area
Figure. 1
