Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH12QC-D3DNC6A/O GWC12QC-D3DNC6A/O
Outdoor Unit Product Code CB443W02900 CB443W02800
Compressor Manufacturer/Trademark
ZHUHAI GREE DAIKIN DEVICE
CO.,LTD
ZHUHAI GREE DAIKIN DEVICE
CO.,LTD
Compressor Model 1GDY23AXD 1GDY23AXD
Compressor Oil DAPHNE FVC50K DAPHNE FVC50K
Compressor Type Swing Swing
Compressor Locked Rotor Amp (L.R.A) A / /
Compressor RLA A 4 4
Compressor Power Input W 845 845
Overload Protector KSD115
O
C or HPC115/95 KSD115
O
C or HPC115/95
Throttling Method Capillary Capillary
Operation temp ºF 61~86 61~86
Ambient temp (cooling) ºF 0~115 0~115
Ambient temp (heating) ºF -4~75 /
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ 2/7 Φ 2/7
Rows-n Gap inch 2-1/18 2-1/18
Coil Length (LXDXW) inch 28X1 1/2X20 28X1 1/2X20
Fan Motor Speed rpm 820 820
Output of Fan Motor W 30 30
Fan Motor RLA A 0.36 0.36
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit CFM 1600 1600
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ400 Φ400
Defrosting Method Automatic Defrosting /
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 53/-/- 53/-/-
Sound Power Level (H/M/L) dB (A) 63//-/- 63//-/-
Dimension (WXHXD) inch 30 9/16X21 1/4X12 5/8 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 33 3/8X14X22 13/16 33 3/8X14X22 13/16
Dimension of Package (LXWXH) inch 33 3/8X14 1/4X23 7/16 33 3/8X14 1/4X23 7/16
Net Weight Ib 69.5 70.6
Gross Weight Ib 75.0 76.1
Refrigerant R410A R410A
Refrigerant Charge oz 30 30
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.2 0.2
Outer Diameter Liquid Pipe inch Φ1/4 Φ1/4
Outer Diameter Gas Pipe inch Φ1/2 Φ3/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 65.6 65.6
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
