Cree GWH09QC-D3DNC2D - Specifications; Specification Sheet

4
Technical Information
Service Manual
Model
GWC12QC-D3DNA6H
GWC12QC-D3DNA3H
GWC12QC-D3DNB8H
Product Code
CB427005800
CB427009700
CB438008500
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 12000(3753~12500)
Heating Capacity(Min~Max) Btu/h /
Cooling Power Input(Min~Max) W 1300(410~1350)
Heating Power Input(Min~Max) W /
Cooling Power Current A 5.8
Heating Power Current A /
Rated Input W 1350
Rated Current A 6.0
Air Flow Volume(SH/H/M/L) CFM 400/318/241/194
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 9.23
COP (Btu/h)/W /
SEER 16.00
HSPF /
Application Area yd
2
19.14-28.70
Indoor Unit
Model of indoor unit
GWC12QC-D3DNA6H/I
GWC12QC-D3DNA3H/I
GWC12QC-D3DNB8H/I
Indoor Unit Product Code
CB427N05800
CB427N09700
CB438N08500
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 7/8X25
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1000/800/-
Fan Motor Heating Speed(SH/H/M/L) r/min /
Output of Fan Motor W 20
Fan Motor RLA A 0.31
Fan Motor Capacitor μF 1.5
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 25X7/8X12 1/16
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 45/39/35/29/-
Sound Power Level(SH/H/M/L) dB (A) 55/49/45/39/-
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11 1/16X15
Net Weight Ib 22.05
Gross Weight Ib 27.56
2. Specications
2.1 Specication Sheet
