Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
GWC12QC-D3DNA6H/I GWH12QC-D3DNA6H/I GWC12QC-D3DNC6A/I
Product Code CB427N05800 CB427N05900 CB443N02800
1 Front Panel 2002266101S 2002266101S 2002247401 1
2 Filter Sub-Assy 11122468 11122468 11122468 2
3 Display Board 30565265 30565265 30565260 1
4 Front Case Assy 2002273101 2002273101 00000200045 1
5 Guide Louver 1051293101 1051293101 1051293101 1
6 Helicoid Tongue 26112436 26112436 26112436 1
7 Left Axile Bush 10512037 10512037 10512037 1
8 Rear Case assy 00000100093 00000100093 00000100093 1
9 Drainage Hose 05230014 05230014 05230014 1
10 Ring of Bearing 26152022 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 7651205102 7651205102 7651205102 1
12 Evaporator Supper 24212179 24212179 24212179 1
13 Cold Plasma Generator / / / /
14 Evaporator Assy 0100297601 0100297601 0100297601 1
15 Wall Mounting Frame 01252484 01252484 01252484 1
16 Cross Flow Fan 10352056 10352056 10352056 1
17 Fan Motor 1501214604 1501214604 1501214604 1
18 Connecting pipe clamp 2611216401 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
20 Stepping Motor 1521210710 1521210710 1521210701 1
21 Crank 73012005 73012005 73012005 1
22 Electric Box Assy 10000201640 10000201640 10000202356 1
23 Axile Bush 10542036 10542036 10542036 1
24 Terminal Board 42011233 42011233 42011233 1
25 Jumper 4202021917 4202021917 4202021917 1
26 Main Board 30138000655 30138000656 30138000655 1
27 Screw Cover 2425203001 2425203001 2425203001 1
28 Electric Box Cover Sub-Assy 0140206501 0140206501 0140206501 1
29 Shield Cover of Electric Box Cover 01592150 01592150 01592150 1
30 Electric Box Cover 2011220701 2011220701 2011220701 1
31 Power Cord / / / /
32 Connecting Cable / / / /
33 Remote Controller 30510475 30510475 30510475 1
Above data is subject to change without notice.
