Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWC12QC-D3DNA6H/O GWC12QC-D3DNC6A/O
Product Code CB427W05800 CB443W02800
1 Front Grill 01473012 01473012 1
2 Front Panel Assy 0153304804 0000030001504 1
3 Axial Flow Fan 10333004 10333004 1
4 Fan Motor 1501306723 1501306723 1
5 Chassis Sub-assy 017000000057P 02803187P 1
6 Compressor Gasket 76710287 76713027 3
7 Compressor and ttings 00103364 00103892 1
8 Valve Support 0171314201P 0171314201P 1
9 Cut off Valve Assy 07133474 071302391 1
10 Valve Support Block 26113017 26113017 2
11 Valve 07133082 07133082 1
12 Cable Cross Plate 2 02123014P 02123014P 1
13 Right Side Plate Assy 013030713 013030713 1
14 Cover of pass wire 01413069 01413069 1
15 Inhalation Tube Sub-assy 030010000181 03001000262 1
16 Discharge Tube 035008000337 03500800570 1
17 Temperature Sensor 3900030805 3900030805 1
18 Capillary Sub-assy 030006000137 03000600339 1
19 Rear Grill 01473009 01473009 1
20 Condenser Assy 011002000133 01100200360 1
21 Clapboard Sub-Assy 0123338502 0123338502 1
22 Top Cover Sub-Assy 01253073 01253073 1
23 Motor Support 0170310401 0170310401 1
24 Electric Box Assy 10000100886 100002003479 1
25 Reactor 43130184 43130184 1
26 Electric Box Cover Sub-Assy 10000500541 017007000562 1
27 Main Board 30138001267 300027000540 1
28 Terminal Board 42010313 42010313 1
29 Wire Clamp 71010003 71010003 1
30 valve cover 2012300101 2012300101 1
To Next Page
