NO.
Description
Part Code
Qty
GWH12QC-D3DNA6H/O GWH12QC-D3DNC6A/O
Product Code CB427W05900 CB443W02900
1 Front Grill 01473012 01473012 1
2 Front Panel Assy 0153304804 0000030001504 1
3 Axial Flow Fan 10333004 10333004 1
4 Chassis Sub-assy 017000000057P 01700000081P 1
5 Clapboard Sub-Assy 0123338502 0123338502 1
6 Drainage Connecter 06123401 06123401 1
7 Compressor Gasket 76710287 76713027 3
8 4-Way Valve Assy 030152000094 03073277 1
9 Valve Support 0171314201P 0171314201P 1
10 Cut off Valve Assy 07133474 071302391 1
11 Valve 07133082 07133082 1
12 Valve Support Block 26113017 26113017 2
13 Cover of Pass Wire 01413069 02123014P 1
14 Right Side Plate Assy 013030713 013030713 1
15 Cable Cross Plate 2 02123014P 01413069 1
16 Magnet Coil 4300040050 4300040050 1
17 Capillary Sub-assy 030006000141 01473009 1
18 Rear Grill 01473009 03000600327 1
19 Electric Box 20113033 20113033 1
20 Main Board 30138001268 300027000541 1
21 Reactor 43130184 43130184 1
22 Electric Box Assy 10000100885 100002003470 1
23 Terminal Board 42010313 42010313 1
24 Wire Clamp 71010003 71010003 1
25 Top Cover Sub-Assy 01253073 01253073 1
26 Condenser Assy 011002000134 01100200346 1
27 Motor Support 0170310401 0170310401 1
28 Fan Motor 1501306723 1501306723 1
29 Compressor Overload Protector(External) / 00183111 1
30 Compressor and Fittings 00103364 00103892 1
31 Small Handle 26233100 26233100 1
32 Temperature Sensor 3900030805 3900030805 1
33 valve cover 2012300101 2012300101 1
