Regulators repair and maintenance
January 2008 Rev. ELL. OCTO /A Ed. B / 09 11
2nd stage ELLIPSE Black
• Cam-lock –disassembling the regulator
• Insert a 4 mm (0,15 in.) Allen wrench in the cam-lock, slightly press
and turn 90° anticlockwise. The inside spring will push out the key,
so that it may be easily taken out.
HZ 810077
