Crest Audio X-VCA - Model 5 A Power Supply

p. 140
model 5A power supply
specifications
+18V @ 5A DC
-18V
@ 5A DC
+12V @ 4A DC
+48V @ 0.75A DC
two Hirose JR16RK-7S connectors on rear
connector meets
JIS C 5432 standard
grey polyurethane outer jacket, 15 feet long
seven-way, 14-gauge stranded conductors
rated
600 volts, 80 degrees C
UL and CSA approved
Hirose
JR16PK-7S and JR16PK-7P connectors fitted
90 to 250 volts @ 4.5 amps maximum
universal
AC input voltage. No changes needed
0.5 amps idle
IEC 320 C-13 3-pin 15 amp receptacle
removable IEC type
with country-specific mains plug fitted
UL, CSA, and CE
two-
space 19 inch rack mount unit
3.5 inches tall, 17 inches wide, 12 inches deep.
weight:
18 pounds
output power
DC out receptacle
DC out cable
AC mains power supply
AC
mains receptacle
cable
approvals
chassis
X-VCA owner’s manual
power supply
8
