p. 35
stereo input module
metering features
Balance control
See description of Bus Assignment features later in this section
safe preview
Safe Preview LED
See LOCAL MICROPROCESSOR CONTROL section
mute
Mute switch
See LOCAL MICROPROCESSOR CONTROL section
write-in label
This label may be written on with a grease-marker, or dry-erase pen and later
wiped clean. Masking tape may also be placed on this surface, if desired. If you
write on it with a "Sharpie", you may have trouble getting the writing off. If this is
the case, your best bet is to wipe the label off with isopropyl (rubbing) alcohol.
Left and Right signal LED indicators
Both Left and Right inputs each have their own Peak and Signal present LED's.
peak indicator - PK
The input signal is monitored at the mic preamp, the EQ stage and the fader
stage. Overloads at any of these stages will cause the red peak-LED to light.
signal present indicator—SIG
This green-LED varies in brightness in response to signal levels between -40
dB and -6 dB.
