p. 39
stereo input module
features
input fader
The input fader is the primary level control for signals being sent to any of the
consoles mix buses.The signals affected are the AUX sends selected to be pre-
fader.The fader offers greater than 80dB of attenuation and up to 10dB of boost .
Normal operation is between -10 and 0.The fader itself is a 100mm 10K linear
taper slide potentiometer. It controls the voltage to the channel's VCA. No audio
passes through the fader.
solo switch
Pressing this momentary switch will include (illuminate) or exclude (not-illu-
minated) the channel from the consoles solo system.
See SOLO FEATURES section.
