p. 61
left / right & mono master modules
matrix sends
Due to space considerations, the Left Matrix sends are located on the Left / Right
master module and the Right Matrix sends are located on the Mono master
module. Likewise, the Mono Matrix sends are bumped down one slot and appear
in the Master Control section.To make this more clear, refer to the illustration.
matrix 1–4 levels—M1,M2,M3,M4
These level controls are used to dial the LEFT, RIGHT and MONO signals
into the corresponding matrix.
post-group
The LEFT, RIGHT or MONO fader setting has no effect on the group-to-
matrix level controls 1–4.
The LEFT, RIGHT or MONO fader is introduced into the signal path and
will control the signal level.When the LEFT, RIGHT or MONO is muted, the
LEFT, RIGHT or MONO signals to matrix 1-4 are muted as well.
