Operations Guide - DOC. 8128 CNX MIDI Interface Expansion Card: CNXMIDI •• 1
CNX MIDI Interface Expansion
Card: CNXMIDI
Description
Functional Description
The CNXMIDI, a MIDI Interface Expansion Card provides MIDI IN, OUT, and
THRU interface. Use with devices such as mixers and lighting equipment.
Physical Description
The CNXMIDI, shown below, is a circuit board fastened to an aluminum faceplate.
The card is manufactured to easily fit into an unoccupied slot in a Crestron CNX
Generation Control System.
CNXMIDI Faceplate
5.000 in
(127.00 mm)
CNXMIDI MIDI INTERFACE
0.980 in
(24.89 mm)
THRU
IN
OUT
The faceplate contains three female 5-pin DIN connectors. These are standard MIDI
connectors. Silk screening is applied to the faceplate; jacks are labeled THRU, IN,
and OUT from left to right, as shown above.

Crestron CNXMIDI Specifications

General

Brand	Crestron
Model	CNXMIDI
Category	Computer Hardware
Language	English
