Crestron TPS-6X-DS-C & TPS-6XNL-DS-C Docking Stations
TPS-6X-DS-C Overall Dimensions (Top View)
6.98 in
(178 mm)
6.48 in
(165 mm)
TPS-6X-DS-C (Rear View)
2
Connectors, Controls & Indicators
# CONNECTORS,
CONTROLS &
INDICATORS
DESCRIPTION
1
TOUCHPANEL
CONNECTOR
(1) 10-pin connector for connecting to
touchpanel.
2
POWER (1) 2.1 mm barrel DC power jack;
24 Volt DC power input
(power supply included).
Operations Guide – DOC. 6878B Docking Stations for the TPS-6X Series: TPS-6X-DS-C & TPS-6XNL-DS-C • 5

Crestron TPS-6X-DS-C Specifications

General

Brand	Crestron
Model	TPS-6X-DS-C
Category	Docking Station
Language	English
