quickstart guide
TSW-1052
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
TSW-1052
10.1” Touch Screen
Audio
Features: Built-in microphone and speakers, Rava™ SIP Intercom, multilanguage voice recognition
2
Audio Feedback Formats: MP3
Connectors
LAN PoE: (1) 8-wire RJ-45 with 2 LED indicators
10BASE-T/100BASE-TX Ethernet port, Power over Ethernet compliant
Green and yellow LEDs indicate Ethernet port status
Power Requirements
Power over Ethernet: IEEE 802.3at Type 1 (802.3af compatible) Class 3 (12.95 W) PoE Powered Device
Environmental
Temperature: 32° to 112° F (0° to 45° C)
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 44 Btu/h
Enclosure
Construction: Plastic, smooth black or white finish
Mounting: Surface mount over a 2 or 3-gang electrical box, 2-gang European (DIN 49073) electrical box,
or 2-3/8” H x 3-3/8” W (60 mm H x 86 mm W) cutout; additional wall mount and tabletop options sold separately
Dimensions
Height: 6.46 in (164 mm)
Width: 10.12 in (257 mm)
Depth: 2.03 in (52 mm)
Weight
24 oz (675 g)
NOTES
1. Supports Smart Graphics only. Not compatible with “traditional” UI projects.
2. Voice recognition, web browsing, weather information, and certain other functions require an Internet
connection.
7
Specifications
QUICKSTART DOC. 7576B (2040593, Sheet 2 of 2) 07.14
4
The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, Crestron Toolbox, Rava and Smart Graphics are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Other trademarks, registered trademarks, and trade names
may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims
any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2014 Crestron Electronics, Inc.
For regulatory compliance information, refer to Doc. 7577.
Touch Screen Display
Display Type: TFT active matrix color LCD
Size: 10.1 inch (257 mm) diagonal
Aspect Ratio: 16:10 WXGA
Resolution: 1280 x 800 pixels
Brightness: 400 nits (cd/m
2
)
Contrast: 800:1
Color Depth: 24-bit, 16.7 million colors
Illumination: Edgelit LED
Viewing Angle: ±80° horizontal, ±80° vertical
Touch Screen: Projected capacitive
Buttons
Hard Keys: (5) Projected capacitive push buttons, programmable, pre-labeled with icons for “Power”, “Home”,
“Lights”, “Up”, and “Down”
Reset: (1) Miniature push button on rear panel for hardware reset
Memory
LPDDR2 RAM: 1 GB
Flash: 4 GB
Maximum Project Size: 512 MB
Graphics Engine
Supports Smart Graphics™
1
, multilanguage web browser
2
, multilanguage on-screen keyboard, screensaver
Languages
Touch Screen & Web Browser: TBA
On-Screen Keyboard: Arabic, Chinese (Simplified), Croatian, Czech, Danish, Dutch, English (UK), English (US),
Finnish, French (Canada), French (Switzerland), German, Hebrew, Hungarian, Italian, Japanese, Norwegian
(Bokmal), Polish, Portuguese, Russian, Serbian, Spanish, Swedish, Turkish
Voice Recognition: English (US), English (UK), English (Canada), English (India), English (Australia), English (New
Zealand), English (Generic), French (France), German (Germany), Dutch (Netherlands), Russian (Russia), Czech
(Czech Republic), Spanish (Spain), Italian (Italy), Chinese, Mandarin (China, Simplified), Chinese, Mandarin (Hong
Kong, Simplified), Chinese, Mandarin (Taiwan, Traditional), Chinese, Yue (Hong Kong, Traditional), Japanese
(Japan), Korean (South Korea), Polish (Poland), Portuguese (Brazil), Turkish (Turkey), isiZulu (South Africa) = zu,
English (South Africa) = en_ZA, Afrikaans (South Africa) = af
Communications
Ethernet: 10/100 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, DHCP, IEEE 802.3af and
802.3at Type 1 compliant
Video
Streaming Formats: H.264 (MPEG-4 part 10 AVC), MJPEG
