Crimson CQUAD65 - Page 3

3
CQUAD65-0001
Box 3 (E10)
2.5mm Allen
Wrench
Set screws
(Security)
DD (4)
Set screws
EE (4)
Pipe Connectors
CC (2)
4’ Static Columns
(2)
2’ Static Column
(1)
B
Mount bracket
AA (1)
5mm Short wrench
BB (1)
5mm Allen wrench
A
Horizontal Assembly
DD (1)
3mm Allen wrench
CC (1)
2.5mm Allen wrench
Box 4 (C65) (4 boxes required for CQUAD installation)
Box 4 (C65) continued
C (2)
Extenders
PACKAGE CONTENTS
Contenido del paquete Contenu de l’emballage
M4 / M5 Spacer
R (4)
M6 / M8 Spacer
S (4)
M4 x 12mm
F (4)
M8 x 40mm
P (4)
M5 x 30mm
I (4)
M6 x 12mm
J (4)
M6 x 20mm
K (4)
M6 x 25mm
L (4)
M6 x 30mm
M(4)
M8 x 16mm
N (4)
M8 x 25mm
O (4)
M5 x 10mm
E (16)
M4 x 30mm
G(4)
Multiwasher
V (4)
M8 Washer
U (8)
M8 POM Washer
Y (2)
M8 x 10mm
T (2)
M5 x 12mm
H (4)
D
Retaining collar
DD (2)
Set screws
M10 x 15mm
Q (4)
PACKAGE CONTENTS
Contenido del paquete Contenu de l’emballage
