Pitch Control Adjustment
There are two sets of strobe dots at the edge of the platter, upper set for AC
frequency 50Hz and bottom set for AC frequency 60Hz.
When the platter is spinning, observe the strobe dots on the edge of the platter. As
illuminated by the light coming from the strobe illuminator, if the appropriate row of
strobe dots appears to be stationary, the platter is spinning at the precise rated
speed.
If the dots appear to be moving to the right, the platter is spinning below rated
speed; if they appear to be moving to the left, the platter is spinning above rated
speed.
Needle Replacement
Removing Needle
1. Gently pull down the front edge of the needle.
2. Pull needle forward.
3. Pull out and remove.
Installing Needle
1. Position the needle with its tip facing down.
2. Line up the back of the needle with the cartridge.
3. Insert the needle with its front end at a downward angle and gently lift the front of
the needle upward until it snaps into place.
