7
INLET HOSE CONNECTION
The washer should be connected to the water mains using new hose sets and old hose sets should not be reused.
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to thecold water inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
For Ordinary Tap
① Pull down the collar of the inlet
hose to separate it from the
water tap adapter.
② Loosen the four screws properly
in order to fit into water tap.
③Fit the water tap adapter into
the water tap and tighten the
four screws evenly while
pushing up the adapter so that
the rubber packing can stick to
the water tap tightly.
④ Remove the tape, and screw
connector B into connect A
tightly.
⑤ Connect the inlet hose to the
water tap adapter by pulling
down the collar of the hose end.
⑥ Connect the inlet hose adapter
of the hose to the water inlet of
the washer by turning it
clockwise to be fixed tightly.
•Please check the rubber packing
present inside the inlet hose
adapter of the hose.
① Connect the inlet hose to the
water tap by screwing the
connector tightly.
②Connect the connector- inlet
supplied if necessary.
③Connect the inlet hose adapter
to the water inlet of a washer
and turn it to be fixed.
•Check the packing in the inlet
For Screw-Shaped Tap
Connector A
Connector B
Connector
Connector
Hose
Connector
Connector
inlet
Hose
Connector
TAPE
To Next Page
