The Crossbeats ROADEYE DC01 is a dash camera designed for vehicle use, offering a range of features for recording and monitoring driving activity.

Function Description:

The primary function of the ROADEYE DC01 is continuous video recording. Users can select between FHD 30fps (default) and HD 30fps video resolutions, with higher resolutions resulting in smoother videos but consuming more storage space. The "Movie Chip Time" setting allows for continuous recording with options for Off, 1 minute (default), 3 minutes, or 5 minutes. The dash cam automatically deletes the oldest files when the memory card is full to ensure continuous recording.

The device includes a "Sound Record" feature, which can be toggled On (default) or Off, determining whether audio is captured with the video files. "Exposure" settings allow users to adjust video brightness or darkness according to their preference.

A "Video Time Lapse" function (Off by default, can be set to On) enables the dash cam to sustain longer operational periods by reducing video file size, with videos played back at high speed.

The ROADEYE DC01 also features an Advanced Driver-Assistance System (ADAS). To use ADAS, it must be turned on in the Menu Setting, and the front lens needs to be calibrated on a straight road. Calibration is successful when two green lines coincide with the road, a cross icon is in the middle of the road, and then blue lines coincide with the road while the green lines disappear. It's important to note that ADAS is an auxiliary function with an accuracy rate of up to 90%, which may decrease in adverse weather or complex road scenes. Regular calibration is recommended.

A "Protect Level" feature (Off by default, with options for Low, Middle, High) utilizes a 3-axis impact gravitational accelerometer (G-sensor). When triggered by physical or gravitational impact, the G-sensor locks the current video file as an emergency file, preventing it from being deleted by the loop cycle function.

For parking surveillance, the dash cam offers "Parking Monitoring" which requires a KACAM 3-wires hardwire kit. Once connected, there are three options: Off, Time Lapse Parking Mode, and Impact Detection Parking Mode. In Time Lapse Parking Mode, the dash cam records at 1S/1FPS after the car is shut down. In Impact Detection Parking Mode, the dash cam turns off after the car is shut down but will wake up, record, and lock a video file if vibration is detected within 30 seconds, saving it to the Event folder before shutting down again.

Important Technical Specifications:

Memory Card Support: Class 10 micro-SD card from 16 GB to 128 GB (64 GB suggested). TF card not included.
Battery: 200mAh, primarily for saving files in emergencies. Requires external power for continuous use.
Charging Ports: USB Charging Port 1, USB Charging Port 2.
Rear View Camera Input: Micro AV IN.
Connectivity: WiFi for KACAM app.
Power Supply Frequency: 50 Hz (default) / 60 Hz, adjustable based on regional power supply specifications (60 Hz for USA/North America, 50 Hz for Europe/most Asian countries).

Usage Features:

Installation: The dash cam mounts to the windshield. The USB charging cable connects to a mini-USB port on the dash cam and extends to a car charger, with cable routing along the windshield edge, away from the airbag area.
Auto Power ON/OFF: Connect the car charger to the dash cam and the vehicle's cigarette lighter socket. The dash cam automatically turns ON and starts recording when the car engine is on. It saves the recording and turns OFF within seconds when the car key is turned to the LOCK position.
Manual Power ON/OFF: Press the power button once to turn ON. Press and hold for at least 2 seconds to turn OFF.
Menu Setting: Access settings by pressing the Menu button. Use Up/Down buttons to navigate, OK to confirm, and Menu again to exit.
Playback Mode: Press the Mode button (M) to switch between Video, Photo, and Lock Video playback modes.
- Video Playback: Use Up/Down to select files, Menu to delete, OK to play/pause. Press and hold Up/Down for fast-forward/rewind. Press Mode (M) to exit.
- Photo Playback: Use Up/Down to select files, Menu to delete, OK to view. Press Mode (M) to exit.
- Lock Video Playback: Use Up/Down to select files, OK to play/pause. Press and hold Up/Down for fast-forward/rewind. Press Mode (M) to exit. Protected files cannot be deleted on the dash cam.
KACAM App: Scan a QR code to download the KACAM app from AppStore or Google PlayStore. Connect to the dash cam's WiFi (SSID: "Crossbeats_RoadEye DC01_******", Password: "12345678"). The app allows real-time video viewing, downloading videos, and changing settings. Android users may need to confirm continued connection despite a "No Internet" notification. iPhone users should tap "Keep Trying WiFi" if prompted to avoid disconnection.
Language: Multilingual support, with English as the default.
Volume: Adjustable (Off, High (default), Middle, Low) for beep sounds.
LCD Power Save: (Off by default, with options for 1 min, 2 mins, 3 mins). Turns off the LCD screen after a set time, showing a black background, while the camera remains ON, to prevent driver distraction.
Clock Settings: Allows setting local date and time.
Stamp: (On by default, can be set to Off). Displays the recording time on videos or photos.
Fatigue Warning: (Off by default, with options for 1 hour, 2 hours, 4 hours). The dash cam will emit a sound after working for the selected duration to alert the driver to stay awake.

Maintenance Features:

Memory Card Formatting: Accessible through the menu settings. It is recommended to format the memory card before use.
Format SD Warning: (Off by default, with options for 15 days, 30 days (default), 60 days). The dash cam will alert the user to format the SD card if there are too many emergency lock files impacting loop recording.
Reset Setup: Allows restoring all settings to factory default.
Firmware Version: Provides information about the current firmware, useful for checking for available updates.
Lens Protection: Users should remove the plastic lens screen protector before recording to avoid blurry or blocked videos.
Power Supply: Only use the supplied car charger to prevent frequent reboots or LCD flickering due to insufficient power.
