SYSTEM WIRING 3 CH.
STE REO C ONFIG URATION
SYSTEM WIRING 4 CH.
STE REO C ONFIG URATION
SYSTEM WIRING DUAL BRIDGE D
MONO CON FIGUR ATION
c
3
-
6
04
C3-604 minimum working impedance is 2 Ohm Stereo each Ch. or
4 Ohm Bridged Mono.
CAUTION!
2~8 Ohm 2~8 Ohm 2~8 Ohm 2~8 Ohm
4~8 Ohm
2~8 Ohm 2~8 Ohm
4~8 Ohm
4~8 Ohm
