CD PLAYER
SEL
Page 1 Page 2
ELECTRICAL CONNECTION
C3 501
L
R
Model
RMS Power 13 8VDC
Power 4 ohms 200W x 1
Power 2 ohms 340W x 1
Power 1 ohms 500W x 1
Minimum Speaker Impedance 1 ohm
THD Distortion 0 1
IMD Distortion 0 1
Input Sensitivity 0 1V 2V
Input Impedance 20K
Signal to Noise Ratio 85dB
Remote gain Control 0 1V 2V
Crossover Network
Low Pass Filter 40Hz 180Hz
Bass Boost 0dB 9dB
Size LxWxH 10x4 82x1 78
C3 501
@
@
@
@
.
.
--
.
.
.
..
