24
English
11 Dust bag cover
12 Plug *
13 Filter cleaning hole
14 Upper handle
15 Upper part of the vacuum cleaner (complete)
16 Cable holder
17 Back wheel *
18 HEPA-lter *
19 Sponge lter *
20 Fabric dust bag *
21 Nozzle brush *
22 Crevice nozzle *
23 Rectangular nozzle *
24 Telescopic tube *
25 Air hose *
26 Telescopic tube lock *
27 Water level mark
28 Dust bag lock
29 Cover lock
30 Hose connector (upper)
31 Paper dust bag *
32 Dust bag connection pipe
33 Float
34 Fabric dust bag lock *
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation of power tool
elements
Before carrying out any works on the power tool it
must be disconnected from the mains.
Mounting / dismounting wheels (see g. 1)
Mount wheels 9 as shown in gure 1. Disassembly
operations do in reverse sequence�
Transport handle (see g. 2)
Transport handle 10 can be folded as shown in
g. 2.
Mounting / dismounting suction line elements (see
g. 3)
• Move lock 26, unfold telescopic tube 24, release
lock 26 (see g. 3.1).
• Assemble components of the air line (connect air
hose 25 to telescopic tube 24, connect nozzle 21, 22
or 23) as shown in g. 3.2.
• Disassembly operations do in reverse sequence�
Preparation for operation in triple outlet air
cleaning mode (see g. 4-8)
This mode is recommended to suck in dry ne
dust (plaster, soot, etc.).
• Unlock locks 8 and remove upper part of the vacuum
cleaner 15 (see g. 4).
• Pour clean water to water mark 27 into the base 7
(see g. 5.1).
• Mount HEPA-lter 18 into the upper part of the
vacuum cleaner 15 (see g. 5.2).
• Mount upper part of the vacuum cleaner 15 and
secure it with locks 8 (see g. 6).
• Mount fabric dust bag 20 onto cover 11 as shown
in g. 7.1. Attention: ange of fabric dust bag 20
must be mounted without warp and lock 28 must
snap shut.
• Put cover 11 (with fabric dust bag 20 mounted) into
upper part of the vacuum cleaner 15 and close lock 29
(see g. 7.2).
• Install plug 12 into lower hose connector 6 (see g. 8).
• Assemble the air line and connect air hose 25 to
upper hose connector 30 (see g. 7).
Preparation for operation in dry waste suck in
mode (see g. 4, 9-11)
This mode is recommended to suck in dry waste.
• Unlock locks 8 and remove upper part of the vacuum
cleaner 15 (see g. 4).
• Connect paper dust bag 31 to connection pipe 32
(see g. 9.1). When connecting paper dust bag 31,
take care to connect it to connection pipe 32 evenly
without warp. Cardboard ange of paper dust bag 31
must touch the wall of base 7� Carefully straighten
paper dust bag 31 after installation�
• Mount HEPA-lter 18 into the upper part of the
vacuum cleaner 15 (see g. 9.2).
• Mount upper part of the vacuum cleaner 15 and
secure it with locks 8 (see g. 10).
• Install plug 12 into upper hose connector 30 (see
g. 11).
• Assemble the air line and connect air hose 25 to
lower hose connector 6 (see g. 11).
• Attention: when removing paper dust bag 31 be
careful not to damage it. Do not empty paper dust
bag 31 for further reuse. Paper dust bag 31 is not
reusable, replace it if full.
Preparation for operation in liquid suck in mode
(see g. 4, 12-14)
This mode is recommended to suck in liquids and
moist waste.
• Unlock locks 8 and remove upper part of the vacuum
cleaner 15 (see g. 4).
• Mount sponge lter 19 into the upper part of the
vacuum cleaner 15 (see g. 12.1).
• Check if oat 33 is movable (see g. 12.2). Float 33
must be able to move up and down freely, otherwise
the liquids sucked in may enter the motor and bring it
out of operation�
• Mount upper part of the vacuum cleaner 15 and
secure it with locks 8 (see g. 13).
• Install plug 12 into upper hose connector 30 (see
g. 14).
• Assemble the air line and connect air hose 25 to
lower hose connector 6 (see g. 14).
Initial operating of the power tool
Always use the correct supply voltage: the power sup-
ply voltage must match the information quoted on the
power tool identication plate.
