MANUAL 10068R6
INSTALLATION & OPERATION
MANUAL
Self Generating Steam Jacketed Kettles
EL-20, EL-25, EL-30, EL-40, EL-60, EL-80, EL-100
EP-20, EP-25, EP-30, EP-40, EP-60, EP-80, EP-100
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read
the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: ____________________
CROWN FOOD SERVICE EQUIPMENT
A Middleby Company
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000 www.crownsteamgroup.com
Printed in Canada

Table of Contents

Questions and Answers

  • P
    Pamela WoodsAug 11, 2025
    What to do if my Crown EL-20 has extremely slow cooking time?
    • Y
      Yvonne GeorgeAug 11, 2025
      Several factors can cause extremely slow cooking times. First, air might be present in the kettle jacket; in that case, follow the AIR VENTING INSTRUCTIONS to remove the air. Second, a slow leak may have developed in the jacket; check all fitting connections, including the heating element gasket, and tighten or replace them if necessary. Finally, a heating element might be burnt out; test the elements, and if defective, replace the complete element assembly.
  • D
    David HowardAug 18, 2025
    Why is my Crown EL-20 Kettle cooking so slow?
    • K
      Kathleen AnthonyAug 18, 2025
      Extremely slow cooking time in your Crown Kettle can be caused by a few things. First, air might be trapped in the kettle jacket. To fix this, follow the air venting instructions. Alternatively, there may be a slow leak in the jacket; inspect all fitting connections, including the heating element gasket, and tighten or replace them if needed. Lastly, a burnt-out heating element could be the culprit. Test the elements, and if they're defective, replace the entire element assembly.
  • L
    Luke MartinAug 26, 2025
    What to do if my Crown EL-20 Kettle will not operate when turned on?
    • R
      Rachel HardyAug 27, 2025
      If your Crown Kettle doesn't operate when turned on, there could be several reasons. First, the water level in the jacket might be inadequate; in this case, follow the LOW WATER LEVEL instructions. Second, there might be a defective power switch or loose wire connections; check these components. Finally, the malfunction could be due to a defective thermostat or loose wiring connection(s). If the TEMPERATURE indicator light comes on when the thermostat knob is dialed fully, the kettle should eventually reach its maximum temperature (290?F) and a pressure reading of approximately 40 psi should be evident on the pressure gauge (on kettles rated at 50 psi).
  • A
    Aaron ThompsonSep 3, 2025
    How to fix low water level in Crown EL-20 Kettle?
    • D
      Daniel WilliamsSep 3, 2025
      Low water level in your Crown Kettle may occur from excessive opening of or leakage through the safety relief valve. To resolve this, follow these steps: 1. Trip the safety relief valve lever to relieve all pressure from the kettle jacket. 2. At the exterior rear of the kettle jacket, remove the nut from the air vent. 3. Insert a funnel into the air vent opening and slowly add the indicated amount of clean water. 4. Replace the air vent nut. 5. Follow the AIR VENTING INSTRUCTIONS. 6. Continue normal operating procedure of kettle.

Crown EL-20 Specifications

General IconGeneral
MaterialStainless steel
Automatic Shut-offYes
Boil-dry ProtectionYes
Water Level IndicatorYes
Removable FilterYes
360-degree Swivel BaseYes
Capacity1.7 liters
Power2200 W
Voltage220-240 V
