Crown GN 1002E - Dimensions

EN - 28
2.1 Dimensions
W2
D2
W1
D1
W3
90
o
D3
Space required in use
2
H2 mm
971
W2 mm
580
D2 mm
589,2
2
the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air.
Overall space required in use
3
W3 mm
805
D3 mm
987,5
3
the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow door
opening to the minimum angle
permitting removal of all internal
equipment.
Overall dimensions
1
H1 mm
821
W1 mm
480
D1 mm
500
1
the height, width and depth of the
appliance without the handle.
H1
H2
