MIDI OUT
Standard MIDI
cables plug.
L - AUDIO OUT - R
SUSTAINMIDI OUT
100-240VAC
2022001
BALANCED OUTPUTS
Audio left and right TRS
balanced outputs.
Connect your amplification
system here. PLEASE always
use a stereo system for better
performance!
AC MAIN PLUG INLET
From 100 to 240 VAC.
Suitable for every Country.
HEADPHONES OUT CONNECTOR
POWER ON/OFF
BUTTON
The fun starts here.
SYSTEM USB PORT
USB-host port - use it to connect
USB class compliant MIDI controllers,
USB flash drives.
Max current draw: 300mA.
MIDI IN/OUT USB
Device type B USB port used to connect
Crumar Seventeen to your computer
for both MIDI input and output.
SUSTAIN PEDAL INPUT
Used for sustaining notes.
Plug your sustain pedal before
powering on your instrument.
The pedal polarity is auto-detected.
