23
2 Channel Amplifer - Applications
GP1000.2 / GP1500.2
One 2 Channel Amplifier in Stereo Mode (Front Amplifier) with
One 2 Channel Amplifier in Mono/Subwoofer Mode (Rear Amplifier)
Subwoofer 4 - 8 Ohms
Connect cable from
REMOTE CONTROL with
the input jack from the
amplifier.
Speakers (Left) 2 - 8 Ohms
Speakers (Right) 2 - 8 Ohms
Connect RCA cable from
head-unit with RCA input
(INPUT).
Connect OUTPUT of
Stereo Amplifier with
INPUT of Bass
Amplifier.
Stereo (Front) Amplifier
REMOTEREMOTE
0dB 12dB
Bass Amplifier
