QUICK SETUP REFERENCE
Truss Rod – Relief
Measure At Condition Specication Notes
8th Fret Hold down rst and last frets Guitar: 0.010”
Bass: 0.015”
Guitar: Check on 6th string
Bass: Check on 4th string
Bridge – Action (String Height)
Measure At Condition Specication Notes
17th fret Clearance between string and fret Guitar: 5/64” (2mm)
Bass: 3/32”
Unfretted
Nut
Measure At Condition Specication Notes
First fret Clearance between string and fret 0.020” – 0.022”
Unfretted
Pickup Height
Measure At Condition Specication Notes
Pickup Depress last fret Guitar: 1/16” – 1/8”
Bass: 3/32” – 1/8”
Adjust for equal volume on all strings
Bridge – Intonation
Condition Result Notes
Fret and harmonic at 12th string Fretted note sharp Lengthen string
Fretted note at Shorten string
Use the blanks to write in your brand-specic setup parameters, if applicable.
