CS Yachts CS36T - Table 6 Running Rigging

CS36T Owner’s Manual Page 44
Table 6 Running Rigging
Standard Rigging Layout
Item No. Layout Material End End Blocks
Main
Halyard
1
Wire 54’
Rope tail 55’
Wire - 3/16” 7x19 SS Rope
–
7/16 Dacron Braid – Yellow
Fleck
Spliced direct into
Merriman shackle 390
Whip
Genoa
Halyard
1
Wire 55’
Rope tail 53’
Wire - 3/16” 7x19 SS Rope
–
7/16 Dacron Braid – Yellow
Fleck
Spliced direct into Nicro
Fico snap shackle NF-
15000S
Whip
Topping Lift 1 Rope 107’
Rope 5/16” Dacron Braid
White
Spliced direct into Nicro
Fico snap shackle NF-
11000S
Whip
Main Sheet 1 Rope 90’
Rope 7/16” Dacron Braid
White
Soft eye for becket of block Whip
Lewmar 9257
Fiddle
Lewmar 9267
Fiddle & Becket
Genoa
Sheets
2 Rope 55’
Rope 5/8” Dacron Braid Blue
Fleck
Whip Whip
Flattening
Reef
First Reef
Clew
Outhaul
1
1
1
Rope 37’
Rope 47’
Rope 3/8” Dacron Green
Fleck
Rope 3/8” Dacron White
Rope 3/8” Dacron Black &
Yellow Fl.
Whip Whip
Optional Rigging Layout
Item No. Layout Material End End Blocks
Spinnaker
Halyard
1
Rope
115’
Rope 7/16” Dacron Braid
Red Fleck
Spliced direct into Nicro Fico
snap shackle NF- 15000S
Whip
Spinnaker Pole
Lift
1
Rope
80‘
Rope 3/8” Dacron Braid
Red Fleck
Spliced direct into Nicro Fico
snap shackle NF- 11000S
Whip
Spinnaker
Sheets
2
Rope
75‘
Rope 1/2” Dacron Braid
Red Fleck
Spliced direct into Nicro Fico
snap shackle NF- 15000S
Whip
Nicro Fico 10124B
snatch snap block
Spinnaker Guy 2
Rope
45‘
Rope 1/2” Low Stretch
Dacron Braid Red Fleck
Spliced direct into Lewmar
snap shackle 5201
Whip
Nicro Fico 10124B
snatch snap block
Spinnaker
Foreguy
1
Rope
56‘
Rope 7/16” Dacron Braid
Red Fleck
Spliced direct into Nicro Fico
snap shackle NF- 11000S
Whip
Lewmar 9218 Single
with snap shackle
Main sheet
Coach Roof
1
Rope
90‘
Rope 7/16” Dacron Braid
White
Soft eye for becket of block Whip
