CS36T Owner’s Manual Page 6
2 SPECIFICATIONS AND DIMENSIONS - CS 36T
2.1 Dimensions
L.0.A. 36'- 6" 11.13 m
L.W.L. 29'- 3" 8.92 m
Beam 11'- 6" 3.50 m
Draft, Deep 6'- 3" 1.90 m
Draft, Shoal 4' - 11" 1.52 m
Displacement 15,500 lbs. 7,021 kg.
Ballast Keel, Deep 6,500 lbs. 2,944 kg.
Ballast Keel, Shoal 6,650 lbs. 3,012 kg.
2.2 Clearance and Shipping Dimensions
Masthead to waterline (excluding
antenna, etc.)
52' - 10" 16.11 m
Pulpit to waterline (mast lowered) 6’- 7" 2.00 m
Height overall in shipping cradle, Deep
draft
12' - 1" 3.68 m
Height overall in shipping cradle, Shoal
draft
10' - 10" 3.30m
Shipping weight in cradle with spars
approx.
16,300 lbs. 7393 kg.
Mast length 54' - 5" 16.58 m
Mast section 5.3" x 7.9" 127 x 205 mm
