CSL ACROBAT - Step 5 - Remove the Module

Step 4-1 :
Release the Screw
of Lock for Rotation.
Step 4-2 :
Rotate the module
Anticlockwise to the stop position.
STEP 4 - ROTATE THE MODULE
STEP 5 - REMOVE THE MODULE
Step 4-3 :
Tighten the Screw
of Lock for Rotation.
MAINTENANCE GUIDE
IC HOUSING | ACROBAT
Step 5-1 :
Release the Screws
of Lock for safety
to this level.
Step 5-2 :
Twist and unlock the
module anticlockwise.
Step 5-3 :
Remove the module.
