CSL CS2369 User Manual

7
ADVANCED CELL PROPERTIES
PARAMETER DESCRIPTION TECHNOLOGY
Network The network to which the cell belongs 2G, 3G, 4G
Type The radio technology 2G, 3G, 4G
Cell Number The cell number you are investigating 2G, 3G, 4G
ARFCN
The cell carrier assigned radio channel (BCCH - Broadcast
Control Channel)
2G
BSIC Base Station Identification Code 2G
RSSI (RxLev) Reception Level (in dBm) 2G, 3G, 4G
BER Bit Error Rate (in %) 2G
MCC Mobile Country Code 2G, 3G, 4G
MNC Mobile Network Code 2G, 3G, 4G
LAC Location Area Code 2G, 3G
CELLID Cell Identifier 2G, 3G
Cell Status
Cell status; Outputs [suitable, low priority based on the received
system information, forbidden, barred based on the received
system information, low level, unknown]
2G, 3G, 4G
NUMARFCN Number of valid channels in the Cell Channel Description 2G
ARFCNN ARFCN of a valid channel in the Cell Channel Description 2G
NUM CHANNELS Number of valid channels in the BCCH Allocation list 2G
BAN The ARFCN of a valid channel in the BA list 2G
SCR CODE Scrambling Code 3G
RSCP Received Signal Code Power - RSCP level (in dBm) 3G
ECIO EC/IO ratio level (in dB) 3G
BW Bandwidth (in MHz) 4G
TAC Tracking Area Code 4G
UARFN
The cell carrier frequency designated by UTRA Absolute Radio
Frequency Channel
3G
EARFCN
Cell carrier frequency designated by EUTRA Absolute Radio
Frequency Channel Number
4G
PHY CELL ID Physical Cell ID 4G
RSRP Reference Signal Received Power 4G
RSRQ Reference Signal Received Quality - RSRQ level (in dBm) 4G
RESULTS
TOP NETWORKS
Shows the highest signal strength readings for each available network in your location; up to 5 networks will
be displayed (if available). Press the right arrow to enter the Best Cells section.
BEST CELLS
Shows the highest signal strength readings across all technologies and networks in your location; up to 5 cells
will be displayed (if available). Press the right arrow to enter the Cell Properties section.
CELL PROPERTIES
Shows basic information for each cell. To view advanced information press the screen in the appropriate area.
See below for more information. If further results are available use the down arrow to view these.
