PERFORMING A SITE SURVEY
WIFI SURVEY
1. Select the Wi-Fi icon on the home screen
2. Select the Start icon for the survey to begin. If you wish to name the survey before you start
select the Name Survey Icon
, name your survey, and press Go
3. A survey progress bar will then display, showing the progress of the survey. The survey should take
5-10 seconds
4. Once the survey has been completed the results will be available
RESULTS
TOP SSID
Shows the highest signal strength readings for each available SSID in your location and the number of Access
Points (APs); up to 5 networks will be displayed (if available). Press the right arrow to enter the Best Access
Points section.
BEST ACCESS POINTS
Shows the Best Access Points for your location and the channel number. Press the right arrow to enter the
Access Point section.
ACCESS POINT PROPERTIES
Shows basic information for each SSID. To view advanced information, press the screen in the appropriate area.
See below for more information. If further results are available use the down arrow to view these.
PARAMETER DESCRIPTION
SSID NAME Wi-Fi network name
ENCRYPTION Wi-Fi security protocol
MAC Media Access Control (device identifier)
RSSI
Received Signal Strength Indicator (in
dBm)
SIG Signal Strength (%)
FREQ OFFSET Frequency Oset of Access Points
FREQ CALIB Calibration for Frequency Oset
CHN Channel
9
