Page #11 background imageLoading...
Page #11 background image
-11-
Technical Data
Rotational Laser Level RL25H RL25HV
Working range (diameter)
– without laser receiver, approx.
– with laser receiver, approx.
2000 ft (609.6 m)
200 ft (60 m)
2000 ft (609.6 m)
Leveling Accuracy
1, 2
3/32 in @ 100 ft (±0.08mm/m) 3/32 in @ 100 ft (±0.08mm/m)
Self-leveling range, typically
±8% (± 5°) ±8% (± 5°)
Leveling duration, typically
15 s 15 s
Rotational speed
600 rpm 0, 150, 300, 600 rpms
Aperture angle
10/25/50 degrees
Operating temperature
3
+14°F to +122°F (–10 to +50°C) +14°F to +122°F (–10 to +50°C)
Storage temperature
-4°F to +158°F (–20 to +70°C) -4°F to +158°F (–20 to +70°C)
Relative air humidity, max.
90% 90%
Laser class
2 3R
Laser type
635nm, <1mW 635nm, >1mW
Laser beam Ø at the exit opening,
approx.
.2 in (5mm) .2 in (5mm)
Tripod mount (horizontal)
5/8"–11 5/8"–11
Batteries (alkali-manganese)
3 x 1.5v (D) 3 x 1.5v (D)
Operating life time, approx.
–Batteries (alkali-manganese)
85h 55h
Weight
5.15 lbs 5.18 lbs
Dimensions (length xwidth xheight)
7.3 x 8.6 x 7.8 in (185x218x198mm) 7.3 x 8.6 x 7.8 in (185x218x198mm)
Degree of protection
IP56 (dust-proof and protected
against water jets)
IP56 (dust-proof and protected
against water jets)
1) at 20°C (68º F) and a temperature drift coefficient of ±1 arc sec per 1º C must be considered for any temperature deviation
above or below standard temperature. It is recommended that you periodically check your rotary laser upon receipt and peri
odically thereafter to ensure accuracy is maintained.
2) alongside the axes
3) It is the user’s responsibility to check the rotary laser accuracy if the operating temperature is exceeded.
Please observe the article number on the type plate of your measuring tool. The trade names of the individual measuring tools may
vary. The measuring tool can be clearly identified with the serial number 13 on the type plate. The rotary laser is designed to with-
stand a drop test of 1M. However it is the user’s responsibility to check the laser’saccuracy after any type of impact such as a drop.
Rotational Laser Level
The measuring tool is intended for determining and checking precise horizontal and vertical
(RL25HV only) lines. The measuring tool is suitable for indoor and outdoor use.
Intended Use
