CST rl25hv User Manual

-28-
Indicating a Plumb Line/Vertical Plane
(see figure B)
To indicate a plumb line or a vertical plane,
set up the laser tool in the vertical position.
When the vertical plane is supposed to run at a
right angle to a reference line (e.g. a wall), then
align the plumb beam
15 with this reference
line. The plumb line is indicated by the rotating
laser beam
14.
Working without Laser Detector
(see figure C)
Under favorable light conditions (dark environ-
ment) and for short distances, it is possible
to work without the laser detector. For better
visibility of the laser beam, either select line
operation, or select point operation.
Working with the Laser Detector
(see figure D)
Under unfavorable light conditions (bright
environment, direct sunlight) and for larger
distances, use the laser detector for improved
finding of the laser beam. When working with
the laser detector, select rotational operation
with the highest rotational speed (600 rpm)
Measuring Over Long Distances
(see figure E)
When measuring over long distances, the laser
detector must be used to find the laser beam.
In order to reduce interferences, the laser tool
should always be set up in the center of the
work surface and on a tripod.
Working Outdoors (see figure F)
The laser detector should always be used when
working outdoors. When working on unstable
ground, mount the laser tool onto the tripod
23. Activate the ADS function in order to
avoid faulty measurements in case of ground
vibrations or shock to the laser tool.
Applications RL25H/RL25HV
Overview of LED Indications
On Laser/motor/LED in continuous operation
Off Laser/motor/LED in continuously stopped
nx/s Laser/LED blinks n times/second
N/C No change from previous state
N/C** Will indicate status if enabled or disabled
Laser
Beam
Rotation
of Laser
Green Green Green Red Red
Switching on the tool (1.5s self-
check)
2x/s Off 2x/s 2x/s 2x/s Off 2x/s
Leveling in or re-leveling 2x/s Off N/C 2x/s N/C N/C N/C
Measuring tool leveled in/ready
for operation
On On On On N/C** N/C N/C
Self-leveling range exceeded 2x/s Off Alt 2x/s Alt2x/s Off Off Off
ADS function activated (two axes) N/C N/C On N/C On Off N/C
ADS function activated (one axis) N/C N/C 1x/s N/C 1x/s Off N/C
ADS actuated 2x/s Off N/C On Off 2x/s N/C
ADS function switched off N/C N/C N/C N/C Off Off N/C
Slope function is actuated N/C N/C 1x/s N/C N/C N/C N/C
Hibernation mode Off Off Off 0.2s On Off Off N/C
Battery usable N/C N/C N/C N/C N/C N/C Off
Battery voltage for ≤2 H operation N/C N/C N/C N/C N/C N/C 1x/s
Battery empty Off Off Off Off Off Off On

CST rl25hv Specifications

General

Brand	CST
Model	rl25hv
Category	Laser Level
Language	English
