CSZ Z-Plus - Page 10

Page 10-C
6.6.2.3. Step 2 – Ramp to 85°C at 5°C/min
6.6.2.4. Step 3 – Soak at 85°C for 1 Hr.
6.6.2.5. Step 4 – Ramp to -40°C at 5°C/min
Temp set to 85°C
Ramp Rate set to
5°C/min
Time is automatically
calculated by the ramp rate
and temp set point
Time set to 1 Hr.
Temp set to -40°C
Ramp Rate set to
5°C/min
Time is automatically
calculated by the ramp rate
and temp set point
