CTP Systems dBbox3 - Output Tone and Noise Generation; AES BNC Tone Level; AES BNC Tone Frequency; AES BNC Tone OP Listen

7
Output> AES BNC Tone Level> Sets the output level of the tone from
-60dB to +12dB in 1dB steps. Settings
will be retained in memory.
Output> AES BNC Tone Frequency> Sets the frequency of the tone in third
octave steps from 50Hz to 20kHz.
Output> AES BNC Tone OP listen> Switch to ‘on’ to enable the internal
speaker and volume control for
confidence monitoring.
Output> AES BNC Int.mic Enables the user to speak to
analogue or digital outputs using
the built in microphone.
Output> AES BNC Int.mic Gain> Sets the internal mic gain
or effectively the level on the
outputs.Available settings +12dB,
+6dB, 0dB, -6dB, -12dB
Output> AES BNC Int.mic Limiter> Sets the threshold of the
limiter on the outputs.
Possible settings +12dB, +6dB,
0dB, -6dB, -12dB
Output> AES BNC Int.mic Output> Select to left, right or both
outputs.
Output> AES BNC Noise Gen.
Generates pink or white noise with a frequency range of 20Hz to 20kHz
Output> AES BNC Noise Generator Type> Set output of the noise
Generator to Pink or
White noise.
Output> AES BNC Noise Generator Level> Set output level of the
noise generator from -
60dB to +12dB in 1dB
steps. Setting will be
retained in memory.
