Audio Outputs
All available output signals are the same for analogue, AES and SPDIF signals so will
be described together. Analogue signals go up to +12dBu and digital signals up to
0dBFS.
Output> Analogue
Output> AES BNC
Output> AES XLR
Output> SPDIF BNC
Audio Output Menu
Tone Access the tone menus
Int.Mic Output the built in mic.
Noise Gen. Output pink or white noise
Frame Rate> This item will only show if digital output is
selected. Set to 48kHz or 96kHz as required.
These examples will use AES BNC.
Output> AES BNC Tone Type> Various types of tone output are
available:
Steady Continuous tone both channels.
GLITS Graham’s Line Ident Tone System. Used extensively for
Stereo line identification by the BBC amongst others.
EBU Cyclic break on the left channel, steady on the right.
Sweep Tone rising in frequency from 20Hz to 20kHz. Press Vol- or
Vol+ to start the sweep.
Left Left channel only
Right Right channel only
To Next Page
