CTX EX951F - Page 28

27
!
T901 80A 793 1 LS X'FMR BY LI TAT
!
T902 73A 174 18 L LINE FILTER 1.8UH MIN
!
T903 79A 167120 H DRIVER X'FMR
!
T904 73A 253135 L CHOKE COIL
TP701 9A 211 2 PIN 1.2X15MM
TP702 9A 211 2 PIN 1.2X15MM
VR701 75A 335223 CFVR 22K OHM +-20%
VR702 75A 335204 CFVR 200K OHM +-20%
VR703 75A 335104 CFVR 100K OHM +-20%
VR902 75A 334303 CFVR 30K OHM +-20%
★ X101 93A 22 43 RESONATOR 12.0MHZ
Location
AMP993Z5CT MAIN BOARD FOR P993ZAIWC2N5L
6A 31 4 BRASS
6A 31500 EYELET
6A 31501 BRASS
6A 31502 BRASS
95A 90 23 TIN COATED
715A1027 I CMPC
(R103) 61A 60239252T CFR 3.9K OHM+-5% 1/6W
(R104) 61A 60268252T CFR 6.8K OHM+-5% 1/6W
★ C101 65A 450104 7T 0.1UF +80-20% 50V Y5V
★ C102 67A 309101 3T 100UF +-20% 16V
★ C103 67A 309470 4T 47UF +-20% 25V
C104 65A 44212013T 12PF J NPO 50V
★ C106 65A 444472 5T 4700 PF 10% 50V Y5P
★ C109 65A 450104 7T 0.1UF +80-20% 50V Y5V
★ C110 65A 444102 5T 1000 PF 10% 50V Y5P
★ C111 67A 309100 7T 10UF +-20% 50V
★ C112 67A 309100 7T 10UF +-20% 50V
★ C113 67A 309100 7T 10UF +-20% 50V
C116 65A 44247013T 47PF +-5% NPO 50V
★ C121 67A 309330 3T 33UF +-20% 16V
★ C130 65A 444103 5T 0.01 UF 10% 50V Y5P
★ C131 65A 444103 5T 0.01 UF 10% 50V Y5P
★ C207 65A 444101 5T 100 PF 10% 50V Y5P
★ C401 67A 309109 7T 1.0UF +-20% 50V
★ C402 64A700J1020AT PEN 0.001UF/50V +-5%
C403 65AUP05391 1T 390PF 50V
★ C404 67A 309109 7T 1.0UF +-20% 50V
★ C405 67A 70229 9T 2.2UF +-20% 100V
★ C406 64A700J3330AT 0.033UF 63V +-5%
★ C407 64A176J152 1T 1500PF 100V
★ C408 64A176J104 2T .1UF +-5% 250V
★ C409 67A 309479 7T 4.7UF +-20% 50V
★ C410 65A 442470 9T 47pF/50V SL
★ C412 65A 444101 5T 100 PF 10% 50V Y5P
★ C413 67A 309109 7T 1.0UF +-20% 50V
★ C416 64A176J103 1T 0.01UF 5% 100V
