CUAV V5+ - CAN 2 Interface; CAN 1 Interface; GPS & Safety Interface; I2 C 2 Interface

GND CAN_L CAN_H 5V+
04
CAN 2
GND CAN_L CAN_H 5V+
05
CAN 1
07
I2C 2
GND SDA2 SCL2 5V+
10
GND
GND
VOLTAGE
CURRENT
POWER_IN
POWER_IN
POWER 1
9
GND
GND
SDA1/VOLTAGE
SCL1/CURRENT
POWER_IN
POWER_IN
POWER 2
(default smart battery)
5V+
TX
RX
SCL1
SDA1
SAFETY_SW
SAFETY_SW_LED
SAFE_VCC
BUZZER
GND
06
GPS&SAFTETY
08
I2C 1
GND SDA1 SCL1 5V+
-2-
11 12 13
CAN1
CAN2
ADC SPI5
TF Card
DSM/SBUS/RSSI
内存卡槽
Memory
card slot
-
+
s
1
2
