CUAV V5+ - SBUS OUT Interface; I2 C3 Interface; DEBUG & UART7 Interface; I2 C4 Interface

+
s
-
地面站下载 Download Ground Control Station
-4-
PPM IN
AUX MAIN
M1 M2 M3 M4 M5 M6 M7 M8
A1 A2 A3 A4 A5 A6
https://docs.qgroundcontrol.com/en/getting_started/download_and
_install.html
QGROUNDCONTROL
Mission Planner
http://ardupilot.org/planner/docs/mission-planner-installation.html
GND NC SBUS_OUT
DEBUG&UART7I2C3SBUS OUT I2C4
GND SDA3 SCL3 5V+
GND SDA4 SCL4 5V+ FMU_SWCLK GND FMU_SWDIO DEBUG_RX DEBUG_TX 5V+
14 15 16 17
