Cub Cadet 18M 19-inch User Manual

23
8
Parts List
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
G
E
N
U
I
N
E
F
A
C
T
O
R
Y
P
A
R
T
S
Ref.
No.
Part No. Description
1 787-01362 19” Deck
2 731-05880 Spacer, .515 x 1.00 x .310 Lg.
3 710-1241 Screw, 1/4-15 x 1.000
4 710-04577 Screw, Machine, M4-.7 x 10.00
5 749-04312 Lower Handle
6 631-04232 Engine Shroud
7 736-0504 Washer, Wave, .510 x .750 x .017
8 748-0376C Blade Adapter
9 742-0739 Mulching Blade
10 736-0524B Blade Bell Support
11 710-1044 Screw, 3/8-24 x 1.50
12 731-05639 Trailing Shield
13 731-05746 Rear Mulch Plug
14 731-04177 Side Discharge Chute
15 687-02055 Mulch Plug (Incl. 16-18)
16 732-1014 Torsion Spring
17 747-0710 Hinge Pin
18 17032A Chute Deflector Adapter
19 736-0270 Beleville Washer
20 710-0599 Screw
21 731-05686 Rear Door
22 731-05634 Front Cover
23 687-02290 Handle Bracket - RH
687-02284 Handle Bracket - LH
24 664-04066 Grass Bag
25 647-04082 Grass Bag Frame
26 687-02225 Front Bracket Assembly
27 738-0148 Screw, Shoulder, .50 x .66
28 687-02228 Rear Bracket Assembly
Ref.
No.
Part No. Description
29 710-0260A Bolt, Carriage, 5/16-18 x .62
30 710-1242 Screw, 5/16-14 x .750
31 712-04063 Nut, Flange Lock, 5/16-18
32 712-04065 Nut, Flange Lock, 3/8-16
33 634-04346 Front Wheel
34 634-04347 Rear Wheel
35 720-0230 Foam Grip
36 712-04064 Nut, Flange Lock, 1/4-20
37 749-04355 Upper Handle
38 710-0606 Screw, 1/4-20 x 1.50
39 720-0279 Knob
40 725-0157 Cable Tie
41 710-1205 Rope Guide
42 746-04380 Choke Cable
43 746-04381 Control Cable
44 747-04665 Blade Control
45 710-1174 Bolt Carriage, 5/16-18 x 2.0
46 720-04072 Star Knob
47 731-05710 Rear Baffle
48 732-04264 Door Torsion Spring - RH
732-04265 Door Torsion Spring - LH
49 732-04377 Spring Lever
50 736-0255 Washer, Bell, .510 x 1.14 x .040
51 736-3012A Washer, Wave, .390 x .825 x .016
52 738-0507B Screw, Shoulder, .500 Dia. X .434
53 741-0492A Bushing, Lock, .505 Dia. X .62
54 747-04589 Rear Door Pivot Rod
55 749-04307 Cross Bracket
56 750-04305A Spacer, 6.60mm ID x 9mm OD
