For parts and/or
accessories
please call
(800) 965-4CUB
Part List:
Rear Triple
Bagger
Ref.
No.
Part No. Description
1 17200A Catcher Support Bracket
2 17247 Support Tube Bracket
3 631-0221A Elbow Chute Assembly
4 664-04018 Grass Catcher Cover Assembly
(includes references 34-44)
5 683-0617A Chute Stop Bracket Assembly
6 689-00002 Grass Catcher Support Assembly
7 703-05783 Deflector, 50” Deck
8 710-0106 Hex Cap Screw, 1/4-20 x 1.25
9 710-0597 Hex Cap Screw, 1/4-20 x 1.00
10 710-0751 Hex Cap Screw, 1/4-20 x .62
11 710-3008 Hex Cap Screw, 5/16-18 x .75
12 710-3015 Hex Cap Screw, 1/4-20 x .75
13 710-3168 Carriage Bolt, 3/8-16: 1.00
14 711-0309A Clevis Pin
15 711-04069 Grass Catcher Pin, 1/4-20
16 712-04064 Hex Flange Lock Nut, 1/4-20
17 712-04065 Hex Flange Lock Nut, 3/8-16
18 712-3004A Hex Flange Lock Nut, 5/16-18
19 714-0117 Internal Cotter Pin, .148 x 3
20 723-04008A Chute Strap, 6.00 Long
21 723-0476 Retainer Strap Assembly
22 731-0926B Chute Tube
23 736-0253 Belleville Washer
24 736-0270 Bell Washer, .265 x .75 x .062
25 736-3092 Flat Washer .265 x 1.0 x .030
26 738-0380 Shoulder Screw, .50 x .27, 3/8-16
Ref.
No.
Part No. Description
27 742-04056C Blade, 17.90Lg. Star Mnt, Bag.
28 783-0601 Catcher Support Bracket
29 783-0673B Catcher Support Bracket, RH
30 783-0764B Catcher Support Bracket, LH
31 783-0765 Catcher Support Bracket
32 783-1501 Catcher Spacer Bracket
33 764-0251 Grassbag Assembly
(Includes References 45-50)
34 17202B Bracket Mounting Screen
35 710-1652 Self-tap Screw, 1/4-20 x .625
36 720-04018 Screen
37 726-0233 Push Nut, .25 x .50
38 726-0479 Ratchet Clip
39 728-0123 Pop Rivet
40 731-04189 Grassbag Retainer Seal
41 731-0824A Plastic Plate
42 735-04020 Grassbag Hopper Seal
43 736-0400 Flat Washer, .194 x .62 x .063
44 749-0747 Hinge Bracket Assembly
45 17201A Bag Frame Hanger Bracket
46 710-0473 Screw, #10-24 x .5
47 710-0604A Self-tapping Screw, 5/16-18 x.625
48 712-0272 Hex Sems Nut, #10-24
49 749-0745A Grassbag Frame Tube
50 764-0251 Grass Catcher Bag
51 777D03361 Cub Cadet Logo (if equipped)
52 726-3040 Push Cap (if equipped)
G
E
N
U
I
N
E
F
A
C
T
O
R
Y
P
A
R
T
S
