18
Operate the PTO clutch as follows:
1. Move the throttle control lever to approximately the
mid throttle position.
2. Pull the PTO switch to the “RUN” position.
3. Advance the throttle lever to the operating speed
(full engine speed).
4. The operator must remain in the tractor seat at all
times. If the operator should leave the seat
without turning off the power take-off switch, the
tractor’s engine will shut off.
5. The PTO clutch cannot be operated when the
tractor is driving in the reverse direction. The PTO
switch must in the “OFF” position when the
reverse control pedal is depressed, or the PTO
clutch will automatically disengage. To re-engage
the PTO clutch, release the reverse control pedal,
move the PTO switch to the “OFF” position, then
again pull the switch to the “RUN” position.
DRAWBAR
Drawbar type equipment must be hitched to the tractor
only at the hitch hole in the drawbar (See Figure 9).
Figure 9
